SemaConnect Series 7 Charging Solutions
SemaConnect - Series 7 Charging Solutions
The SemaConnect Series 7 Charging Solutions offers an ideal solution for businesses, apartment complexes, and fleets seeking a reliable and energy-efficient charging station. With its compact form factor and ENERGY STAR® certification, this model ensures both performance and sustainability. The commercial-grade aluminum body guarantees durability, making it suitable for various environments. Additionally, installation is straightforward, allowing for a hassle-free setup.
This dual-port charger can efficiently serve two electric vehicles simultaneously, with a configurable capacity of up to 80A per port. The back-lit LCD screen provides clear, user-friendly operation, and data communication is supported via the built-in 4G LTE, ensuring real-time connectivity.
Charging Speed
The SemaConnect Series 7 Charging Solutions delivers exceptional charging speeds, with configurable ports offering up to 80A maximum per port, ensuring quick and efficient charging for electric vehicles.
Technical Specifications
| ELECTRICAL SPECIFICATION – AC OUTPUT | |
| Number of Ports | Two |
| Current | Configurable up to 48A Max per port |
| Power | Up to 11.52 kW (@240VAC) or 9.984 kW (@208VAC)
Max per port |
| Energy Metering Accuracy | +/- 1% |
| Charging Connector | SAE J1772 |
| ELECTRICAL SPECIFICATION – AC INPUT | |
| Input Connector | Hardwired |
| Voltage | 208 or 240 VAC |
| Service Panel Breaker | Two-pole common trip 60A breaker, dedicated circuit per port |
| Power Connection | Line 1, Line 2 and GND (no neutral) |
| Standby Power | 3.46 W Typical |
| SAFETY SPECIFICATIONS | |
| Ground Fault Circuit Interrupt | 20mA CCID with auto retry (every 15 seconds) |
| Automatic Plug-Out Detection | Power terminated per SAE J1772 spec |
| Surge Protection | 6kV @3,000A |
| NETWORK SPECIFICATIONS | |
| Data Communication | Cellular 4G LTE |
| Charging Infrastructure Communication | OCPP 1.6 compliant |
| Remote Management | Remote access, diagnostics, Over-The-Air (OTA) software update enabled |
| Load Management | Smart, dynamic allocation and distribution of power to each port |
| USER INTERACTION SPECIFICATION | |
| Charging Status Indicator | High visibility, multi-color LED visual status indication |
| Display | LCD Screen - 4 line, 20 characters per line |
| Authentication | RFID: ISO14443 Type A & B, MiFare, Felica, ISO15693 |
| ENVIRONMENTAL SPECIFICATION | |
| Enclosure | Aluminum, NEMA 3R certified |
| Operating Humidity | Up to 95% non-condensing |
| Operating Temperature | -30 degree C to +50 degree C ambient |
| Operating Altitude | <=6560 ft |
| MECHANICAL SPECIFICATION | |
| Dimensions | Charging Head: 20.5” H x 7.4” W x 7.4” D |
| Approximate Weights |
|
| Mounting Option | Wall or Pedestal mount |
| Cable Length | 18 ft standard, 25ft optional |
| Cable Organizer | Optional |
| REGULATION | |
| Safety |
|
| EMI | FCC Part 15 Class A compliant |
| Energy Efficiency | Energy Star Certified |
| Compliance | California Type Evaluation Program (CTEP) certified, Buy American ACT (BAA) compliant |
| Accessibility | ADA Compliant |
| Warranty Protection | N/A |
| User Rating | N/A |
| Price | N/A |
Smart Features of SemaConnect - Series 7 Charging Solutions
- Configurable Charging Options: Ports can be adjusted to deliver up to 80A, offering flexible charging speeds tailored to specific needs.
- Dual-Port Design: This feature enables simultaneous charging of two vehicles, maximizing efficiency and reducing wait times.
- Back-lit LCD Screen: The easy-to-read screen ensures clear visibility of charging status and other essential information, even in low light conditions.
- Built-in 4G LTE Communication: Real-time data transmission via 4G LTE ensures seamless connectivity for remote monitoring and updates.
- Rugged Aluminum Enclosure: The commercial-grade aluminum body ensures durability and resilience, making it suitable for both indoor and outdoor environments.
- Pedestal and Wall-Mount Options: Flexibility in installation allows for optimal placement, whether mounted on a wall or positioned on a pedestal.
Product guides and documents of SemaConnect - Series 7 Charging Solutions
SemaConnect - Series 7 Charging Solutions Product Manual Sheet
SemaConnect - Series 7 - 48A Charging Solutions Technical Specification Sheet
SemaConnect - Series 7 - 48A Fast Charging Solutions Technical Specification Sheet
Advantages of the SemaConnect - Series 7 Charging Solutions
- Energy Efficiency: The ENERGY STAR® certification guarantees that the Series 7 Charger meets stringent energy efficiency standards, helping businesses reduce costs.
- Durability: The rugged aluminum body is built to withstand the elements, ensuring a long lifespan in various environmental conditions.
- Scalability: With dual-port functionality and adjustable charging settings, the Series 7 charger can meet the growing needs of businesses and fleets.
- User-Friendly: The back-lit LCD screen offers an intuitive interface, making operation simple and straightforward for users of all experience levels.
Disadvantages of the SemaConnect - Series 7 Charging Solutions
- Installation Complexity: While installation is relatively simple, some businesses may require professional assistance to ensure proper setup and configuration.
- Limited Charging Speed: While configurable to 80A per port, charging speed may still be slower compared to higher-capacity charging solutions.
- Connectivity Dependency: The reliance on 4G LTE for data communication may present challenges in areas with weak network signals.
- Cost: The Series 7 Charging Solutions may come with a higher upfront cost, which could be a consideration for smaller businesses or apartment complexes.
