ABB Inc Terra T184
ABB Inc. - Terra T184 Charging Station
The ABB Inc. Terra A400 is a high-performance DC fast charger engineered for superior reliability and flexibility across commercial, public, and fleet charging environments. Designed to deliver consistent, intelligent charging for modern electric vehicles, this model provides scalable power options from 120 kW to 180 kW, ensuring future-ready infrastructure adaptability.
Constructed with a durable IP54-rated enclosure, the Terra A400 withstands demanding outdoor and indoor environments. Its advanced connectivity, safety certifications, and remote management capabilities enable smart energy control, while an intuitive touchscreen interface enhances operational efficiency for a seamless charging experience.
Charging Speed
The ABB Inc. Terra A400 delivers up to 180 kW of DC power, enabling vehicles to recover approximately 125 miles of range in under 15 minutes, maximizing uptime and fleet productivity.
Technical Specifications
| Charging Power | Configurable at 120 kW or 180 kW (field-upgradeable) |
| Dynamic Power Sharing | 60–90 kW granularity between dual outlets |
| Output Voltage | 150 – 920 V DC |
| Peak Output Current | CCS: 400 A |
| Power Conversion Efficiency | Up to 96% |
| AC Input (Nominal Voltage) | CE: 400 V (± 10%) |
| AC Input Current (RMS) | T124: CE 187 A / 220 A |
| Frequency | CE: 50 Hz (± 10%) |
| Power Factor | > 0.99 at full load |
| Humidity | Up to 95%, non-condensing |
| Enclosure Rating | IP54 / NEMA 3R (Indoor / Outdoor) |
| Dimensions (H × W × D) | 1900 × 565 × 880 mm (74.8″ × 22.2″ × 34.6″) |
| Weight | T124: 445 kg (981 lbs) |
| Mounting Type | Floor Mounted |
| Display | 7″ LCD Touchscreen Interface |
| Warranty | 5 Years (Standard) |
| Customer Reviews | N/A |
| Price | N/A |
Smart Features of Terra T184
- Dynamic Power Sharing: Intelligent dual-outlet configuration distributes power with 60–90 kW granularity, ensuring efficient load management for multiple vehicles simultaneously.
- Advanced Connectivity: Equipped with LTE, GSM, and Ethernet interfaces supporting OCPP 1.6J and OCPP 2.0.1 for seamless network communication and backend integration.
- Smart Authentication: Supports RFID, Plug & Charge, Autocharge, and optional payment terminals for secure and user-friendly access control.
- Touchscreen Interface: 7-inch LCD display with responsive touchscreen enables intuitive operation and status monitoring under any lighting conditions.
- Intelligent Diagnostics: Remote software updates, configuration, and fault analysis minimize downtime and enhance charger performance reliability.
- Universal Compatibility: Compatible with CCS1, CCS2, J3400 (NACS), and AC socket options for flexible installation across regions and vehicle types.
Product guides and documents
Advantages of Terra T184
- Scalable Charging Power: Field-upgradeable from 120 kW to 180 kW, allowing seamless expansion as charging demand increases.
- High Efficiency: Achieves up to 96% system efficiency, reducing operational costs and maximizing energy utilization.
- Rugged Design: IP54, IK10-rated aluminum enclosure ensures durability in extreme temperatures and outdoor conditions.
- Safety Certified: Complies with global standards including UL 2202, EN IEC 61851, and CTEP/NTEP metering regulations.
Disadvantages of Terra T184
- High Installation Cost: Requires specialized electrical infrastructure and professional setup, increasing overall project expenses.
- Limited Portability: Floor-mounted configuration and heavy construction limit mobility for temporary or small-scale setups.
- Temperature Derating: Performance slightly decreases above 50°C, affecting peak charging output in hot climates.
- Complex Integration: Advanced networking and software setup require trained technicians for full functionality.
- Noise Emission: Generates up to 65 dB(A) during full operation, which may be unsuitable for sound-sensitive areas.
